Description

DA-BLACKALDER

direct
faceted aluminum reflector, 60, tempered glass diffuser
aluminium
white (RAL 9016)
MDA- 220 -240V, 0/50/60Hz
LED lifetime, 60000/L80B10 (T930, T940: 50000/L80B10)
3
I I
IP40
IK0 2
Operating temperature range, ta 0 +35
In ceilings with cut -out openings (mounting brackets included). Push -in terminal, 2x1x1.5mm2
Indoor
Retail, showroom, exhibition, public place

355 horizontal rotation and 60 tilting

* 10%. Values apply to an ambient temperature of 25 C. icLighting is constantly developing and
improving its products. The right is reserved to change any product specifications without prior notification
*Photos are for illustrational purposes only. The exact appearance of the product may vary depending on the monitor settings, options selected and other factors.

Product Length,
mm Width,
mm Height,
mm Luminaire
output*, lm System
power*,
W System
efficacy*,
lm/W CRI *
(Ra) CCT*,
K Weight,
kg
DA-BLACKALDER1x1850 E826 T830 R60 180 180 147 1757 13,5 130 80+ 3000 2,5
DA-BLACKALDER1x2450 E827 T830 R60 180 180 147 2387 18,7 128 80+ 3000 2,5
DA-BLACKALDER1x3250 D784 T830 R60 180 180 147 3214 26,5 121 80+ 3000 2,5
DA-BLACKALDER1x4150 J210 T830 R60 180 180 147 4031 35,1 115 80+ 3000 2,5
DA-BLACKALDER1x4650 D785 T830 R60 180 180 147 4604 40,2 115 80+ 3000 2,5
DA-BLACKALDER1x5050 D786 T830 R60 180 180 147 5120 46,6 110 80+ 3000 2,5
DA-BLACKALDER1x1850 E826 T840 R60 180 180 147 1857 13,5 138 80+ 4000 2,5
DA-BLACKALDER1x2450 E827 T840 R60 180 180 147 2523 18,7 135 80+ 4000 2,5
DA-BLACKALDER1x3250 D784 T840 R60 180 180 147 3397 26,5 128 80+ 4000 2,5
DA-BLACKALDER1x4150 J210 T840 R60 180 180 147 4261 35,1 121 80+ 4000 2,5
DA-BLACKALDER1x4650 D785 T840 R60 180 180 147 4867 40,2 121 80+ 4000 2,5
DA-BLACKALDER1x5050 D786 T840 R60 180 180 147 5413 46,6 116 80+ 4000 2,5
DA-BLACKALDER1x1850 E826 T930 R60 180 180 147 1489 13,3 112 90+ 3000 2,5
DA-BLACKALDER1x2450 E827 T930 R60 180 180 147 2041 18,2 112 90+ 3000 2,5
DA-BLACKALDER1x3250 D784 T930 R60 180 180 147 2773 25,8 107 90+ 3000 2,5
DA-BLACKALDER1x4150 J210 T930 R60 180 180 147 3440 35,1 98 90+ 3000 2,5
DA-BLACKALDER1x4650 D785 T930 R60 180 180 147 3929 40,2 98 90+ 3000 2,5
DA-BLACKALDER1x5050 D786 T930 R60 180 180 147 4370 46,6 94 90+ 3000 2,5
DA-BLACKALDER1x1850 E826 T940 R60 180 180 147 1569 13,3 118 90+ 4000 2,5
DA-BLACKALDER1x2450 E827 T940 R60 180 180 147 2151 18,2 118 90+ 4000 2,5
DA-BLACKALDER1x3250 D784 T940 R60 180 180 147 2923 25,8 113 90+ 4000 2,5
DA-BLACKALDER1x4150 J210 T940 R60 180 180 147 3626 35,1 103 90+ 4000 2,5
DA-BLACKALDER1x4650 D785 T940 R60 180 180 147 4141 40,2 103 90+ 4000 2,5
DA-BLACKALDER1x5050 D786 T940 R60 180 180 147 4606 46,6 99 90+ 4000 2,5
