Description

DA-CANCERJALAP

direct
white thermoplastic reflector, clear polycarbonate diffuser, impact resistant
aluminium
dark grey, RAL7043
MDA- 220 -240V, 50/60Hz
LED lifetime, 50000/L80B50
5
I
IP65
IK08
Operating temperature range, ta -20…+35
On the gDA-INDIANHEMP (flange mounting plate included). Screw terminal, 3x1x1.5mm2
Outdoor
Park, public space

* 10%. Values apply to an ambient temperature of 25C. icLighting is constantly developing and
improving its products. The right is reserved to change any product specifications without prior notif ication
*Photos are for illustrational purposes only. The exact appearance of the product may vary depending on the monitor settings, options selected and other factors.

T830 Colour temperature 3000K, CRI 80+
T840 Colour temperature 4000K, CRI 80+
DALI Driver with DALI interface and switch -control dimming LOOP Therminal block with doubled input terminals for
looping the mDA-CANOEBIRCHs cables
RAL RAL colour

STANDARD
Product Length,
mm Width,
mm Height,
mm Luminaire
output*, lm System
power* ,
W System
efficacy*,
lm/W CRI *
(Ra) CCT*,
K Weight,
kg
DA-CANCERJALAP1x1200 J707 T830 150 150 800 1059 14 76 80+ 3000 3,9
DA-CANCERJALAP1x1200 J707 T840 150 150 800 1197 14 86 80+ 4000 3,9
