Description

DA-CLOVER

direct
opal PMMA diffuser
steel
white (RAL9003)
MDA- 220 -240V, 50 -60Hz
LED lifetime, 100000/L80B50
3
I I
IP4 0/20
IK05
Operating temperature range, ta 0 +35
In modular suspended ceilings (600), in ceilings with cut -out openings (mounting frame to be ordered separately). Push -in terminal,
3x2x2.5mm2
Indoor
Office, education, corridor, retail, public place

* 10%. Values apply to an ambient temperature of 25 C. icLighting is constantly developing and
improving its products. The right is reserved to change any product specifications without prior notification
*Photos are for illustrational purposes only. The exact appearance of the product may vary depending on the monitor settings, options selected and other factors.

Product Length,
mm Width,
mm Height,
mm Luminaire
output*, lm System
power*,
W System
efficacy*,
lm/W CRI *
(Ra) CCT*,
K Weight,
kg
DA-CLOVER1x3400 D067 T830 OP
LT80 595 595 75 3237 26,5 122 80+ 3000 3,1
DA-CLOVER1x4800 D068 T830 OP
LT80 595 595 75 4554 38,5 118 80+ 3000 3,1
DA-CLOVER1x6650 D069 T830 OP
LT80 595 595 75 6312 54,8 115 80+ 3000 3,1
DA-CLOVER1x3400 D067 T840 OP
LT80 595 595 75 3392 26,5 128 80+ 4000 3,1
DA-CLOVER1x4800 D068 T840 OP
LT80 595 595 75 4770 38,5 124 80+ 4000 3,1
DA-CLOVER1x6650 D069 T840 OP
LT80 595 595 75 6612 54,8 121 80+ 4000 3,1

DA-CLOVER1x3150 D067 T830 DPRZ
LT80 595 595 75 2992 26,5 113 80+ 3000 3,1
DA-CLOVER1x4450 D068 T830 DPRZ
LT80 595 595 75 4208 38,5 109 80+ 3000 3,1
DA-CLOVER1x6150 D069 T830 DPRZ
LT80 595 595 75 5833 54,8 106 80+ 3000 3,1
DA-CLOVER1x3150 D067 T840 DPRZ
LT80 595 595 75 3135 26,5 118 80+ 4000 3,1
DA-CLOVER1x4450 D068 T840 DPRZ
LT80 595 595 75 4408 38,5 115 80+ 4000 3,1
DA-CLOVER1x6150 D069 T840 DPRZ
LT80 595 595 75 6110 54,8 111 80+ 4000 3,1

DA-CLOVER1x3400 E907 T830 OP
LT80 W625 622 622 75 3237 26,5 122 80+ 3000 3,3
DA-CLOVER1x4800 E908 T830 OP
LT80 W625 622 622 75 4554 38,5 118 80+ 3000 3,3
DA-CLOVER1x6650 E909 T830 OP
LT80 W625 622 622 75 6312 54,8 115 80+ 3000 3,3
DA-CLOVER1x3400 E907 T840 OP
LT80 W625 622 622 75 3392 26,5 128 80+ 4000 3,3
DA-CLOVER1x4800 E908 T840 OP
LT80 W625 622 622 75 4770 38,5 124 80+ 4000 3,3
DA-CLOVER1x6650 E909 T840 OP
LT80 W625 622 622 75 6612 54,8 121 80+ 4000 3,3

DA-CLOVER1x3150 E907 T830 DPRZ
LT80 W625 622 622 75 2992 26,5 113 80+ 3000 3,3
DA-CLOVER1x4450 E908 T830 DPRZ
LT80 W625 622 622 75 4208 38,5 109 80+ 3000 3,3
DA-CLOVER1x6150 E909 T830 DPRZ
LT80 W625 622 622 75 5833 54,8 106 80+ 3000 3,3
DA-CLOVER1x3150 E907 T840 DPRZ
LT80 W625 622 622 75 3135 26,5 118 80+ 4000 3,3
DA-CLOVER1x4450 E908 T840 DPRZ
LT80 W625 622 622 75 4408 38,5 115 80+ 4000 3,3
DA-CLOVER1x6150 E909 T840 DPRZ
LT80 W625 622 622 75 6110 54,8 111 80+ 4000 3,3
