Description

DA-COAKUM

direct
matt micro -prismatic PMMA diffuser/ translucent micro -prismatic PMMA diffuser
steel
white (RAL9003S)
MDA- 220-240V, 0/50/60Hz
LED lifetime, 50000/L80B10
3
I
IP44
IK05
Operating temperature range, ta 0+35
In modular suspended ceilings, in ceilings with cut -out openings (mounting frame to be ordered separately). Push -in terminal,
3x2x2.5mm2
Indoor
Office, education, corridor, retail, public place

* 10%. Values apply to an ambient temperature of 25C. icLighting is constantly developing and
improving its products. The right is reserved to change any product specifications without prior notif ication
*Photos are for illustrational purposes only. The exact appearance of the product may vary depending on the monitor settings, options selected and other factors.

Product Length,
mm Width,
mm Height,
mm Luminaire
output*, lm System
power* ,
W System
efficacy*,
lm/W CRI *
(Ra) CCT*,
K Weight,
kg
DA-COAKUM1x2350 J229 T830 DPRZ
LT80 595 595 82 2221 17,1 130 80+ 3000 3,0
DA-COAKUM1x2900 J230 T830 DPRZ
LT80 595 595 82 2754 21,2 130 80+ 3000 3,0
DA-COAKUM1x3450 J231 T830 DPRZ
LT80 595 595 82 3276 25,4 129 80+ 3000 3,0
DA-COAKUM1x3950 J232 T830 DPRZ
LT80 595 595 82 3753 29,7 126 80+ 3000 3,0
DA-COAKUM1x4950 J233 T830 DPRZ
LT80 595 595 82 4690 38,9 121 80+ 3000 3,0
DA-COAKUM1x2350 J229 T840 DPRZ
LT80 595 595 82 2326 17,1 136 80+ 4000 3,0
DA-COAKUM1x2900 J230 T840 DPRZ
LT80 595 595 82 2884 21,2 136 80+ 4000 3,0
DA-COAKUM1x3450 J231 T840 DPRZ
LT80 595 595 82 3430 25,4 135 80+ 4000 3,0
DA-COAKUM1x3950 J232 T840 DPRZ
LT80 595 595 82 3929 29,7 132 80+ 4000 3,0
DA-COAKUM1x4950 J233 T840 DPRZ
LT80 595 595 82 4910 38,9 126 80+ 4000 3,0

DA-COAKUM1x2600 J229 T830 MPRZ
LT92 595 595 82 2468 17,1 144 80+ 3000 3,0
DA-COAKUM1x3250 J230 T830 MPRZ
LT92 595 595 82 3060 21,2 144 80+ 3000 3,0
DA-COAKUM1x3850 J231 T830 MPRZ
LT92 595 595 82 3640 25,4 143 80+ 3000 3,0
DA-COAKUM1x4400 J232 T830 MPRZ
LT92 595 595 82 4170 29,7 140 80+ 3000 3,0
DA-COAKUM1x5500 J233 T830 MPRZ
LT92 595 595 82 5211 38,9 134 80+ 3000 3,0
DA-COAKUM1x2600 J229 T840 MPRZ
LT92 595 595 82 2584 17,1 151 80+ 4000 3,0
DA-COAKUM1x3250 J230 T840 MPRZ
LT92 595 595 82 3204 21,2 151 80+ 4000 3,0
DA-COAKUM1x3850 J231 T840 MPRZ
LT92 595 595 82 3811 25,4 150 80+ 4000 3,0
DA-COAKUM1x4400 J232 T840 MPRZ
LT92 595 595 82 4366 29,7 147 80+ 4000 3,0
DA-COAKUM1x5500 J233 T840 MPRZ
LT92 595 595 82 5456 38,9 140 80+ 4000 3,0
