Description

DA-COMMONONION LED

direct
lenses, polycarbonate diffuser, impact resistant
aluminium
Light grey, RAL 9006
MDA- 220 -240V, 0/50 -60Hz
LED lifetime, 50000/L80B10
5
I
IP66
IK08
Operating temperature range, ta -25…+40
With three screws on DA-COMMONTANSYs 60mm. Push -in terminal, 3x2x2.5mm2
Outdoor
Park, public space

* 10%. Values apply to an ambient temperature of 25C. icLighting is constantly developing and
improving its products. The right is reserved to change any product specifications without prior notification
*Photos are for illustrational purposes only. The exact appearance of the product may vary depending on the monitor settings, options selected and other factors.
Product Length,
mm Width,
mm Height,
mm Luminaire
output*, lm System
power*, W System
efficacy*,
lm/W CRI *
(Ra) CCT*,
K Weight,
kg
DA-COMMONONION1x5300 J674 T830 500 500 523 4852 39,3 123 80+ 3000 9
DA-COMMONONION1x7400 J675 T830 500 500 523 6802 58,3 117 80+ 3000 9
DA-COMMONONION1x9350 J708 T830 500 500 523 8649 78,1 111 80+ 3000 9
DA-COMMONONION1x5300 J674 T840 500 500 523 5275 39,3 134 80+ 4000 9
DA-COMMONONION1x7400 J675 T840 500 500 523 7394 58,3 127 80+ 4000 9
DA-COMMONONION1x9350 J708 T840 500 500 523 9328 78,1 119 80+ 4000 9

T830 Colour temperature 3000K, CRI 80+
T840 Colour temperature 4000K, CRI 80+
DALI Driver with DALI interface and switch -control dimming
ADIM Driver with autonomous two -level dimming CBF3x1.5 -N m Outgoing flexible cable 3×1.5mm , length according to
customer specification
CBF5x1.5 -N m Outgoing flexible cable 5×1.5mm , length according to
customer specification
*note – please specify the length of outgoing cable before placing an order
STANDARD
