Description

DA-FEVERFEW

direct
opal polycarbonate diffuser, impact resistant
polycarbonate
white
MDA- 220 -240V, 0/50/60Hz
LED lifetime, 100000/L80B10
3
I
IP54
IK08
Operating temperature range, ta -15+35
On ceiling or wall. Push -in terminal, 3x2x2.5mm2
Indoor
Office, education, corridor, staircase, healthcare, public place

* 10%. Values apply to an ambient temperature of 25 C. icLighting is constantly developing and
improving its products. The right is reserved to change any product specifications without prior notification
*Photos are for illustrational purposes only. The exact appearance of the product may vary depending on the monitor settings, options selected and other factors.

T830 Colour temperature 3000K, CRI 80+
T840 Colour temperature 4000K, CRI 80+
DALI Driver with DALI interface
MW Integrated microwave (MW) motion sensor with on -off control
EM3 Emergency version 3 hour
EM3B Emergency version 3 hours (best available technology)
5TB 5-DA-COMMONTANSY terminal block in middle of luminaire for easy through wiring

OP LT80

Product Length,
mm Width,
mm Height,
mm Luminaire
output*, lm System
power*,
W System
efficacy*,
lm/W CRI *
(Ra) CCT*,
K Weight,
kg
DA-FEVERFEW1x2650 G467 T830 OP
LT80 1160 110 85 2203 17,1 129 80+ 3000 1,9
DA-FEVERFEW1x3400 G468 T830 OP
LT80 1160 110 85 2872 21,6 133 80+ 3000 1,9
DA-FEVERFEW1x4450 G469 T830 OP
LT80 1160 110 85 3743 29,1 128 80+ 3000 1,9
DA-FEVERFEW2x2650 G470 T830 OP
LT80 1160 160 85 4405 33,4 132 80+ 3000 2,6
DA-FEVERFEW2x3300 G471 T830 OP
LT80 1160 160 85 5567 43,5 128 80+ 3000 2,6
DA-FEVERFEW2x3900 G472 T830 OP
LT80 1160 160 85 6608 50,1 132 80+ 3000 2,6
DA-FEVERFEW1x2650 G467 T840 OP
LT80 1160 110 85 2594 17,1 152 80+ 4000 1,9
DA-FEVERFEW1x3400 G468 T840 OP
LT80 1160 110 85 3383 21,6 157 80+ 4000 1,9
DA-FEVERFEW1x4450 G469 T840 OP
LT80 1160 110 85 4409 29,1 151 80+ 4000 1,9
DA-FEVERFEW2x2650 G470 T840 OP
LT80 1160 160 85 5217 33,3 157 80+ 4000 2,6
DA-FEVERFEW2x3300 G471 T840 OP
LT80 1160 160 85 6563 43,3 152 80+ 4000 2,6
DA-FEVERFEW2x3900 G472 T840 OP
LT80 1160 160 85 7783 50,1 155 80+ 4000 2,6
