Description

DA-INDIANPOSY

direct
faceted aluminium reflector, 40, low glare
aluminum
white (RAL9016)
MDA- 220 -240V, 50/60Hz
LED lifetime, 60000/L80B10
3
I
IP20
IK0 2
Operating temperature range, ta 0 +35
On the ceiling. Push -in terminal, 3x2x2.5mm2
Indoor
Office, education, hotel, corridor, bathroom, retail, showroom, exhibition, public place

* 10%. Values apply to an ambient temperature of 25 C. icLighting is constantly developing and
improving its products. The right is reserved to change any product specifications without prior notification
*Photos are for illustrational purposes only. The exact appearance of the product may vary depending on the monitor settings, options selected and other factors.

T830 Colour temperature 3000K, CRI 80+
T840 Colour temperature 4000K, CRI 80+
T927 NATURAL Colour temperature 2700K, CRI 95+ NATURAL
T930 NATURAL Colour temperature 3000K, CRI 95+ NATURAL
T940 NATURAL Colour temperature 4000K, CRI 95+ NATURAL
DALI Driver with DALI interface and switch -control dimming
1G StrDA-CANOEBIRCH relief for power supply cable
SUS Suspended version
RAL RAL colour

STANDARD Suspension MTG KIT SUSI
Suspension wire set “I” type, 1.5m adjustable, 1pcs
*note – 1pcs MTG KIT SUSI for one fitting required
*note – SUS option is required

Product Length,
mm Width,
mm Height,
mm Luminaire
output*, lm System
power*,
W System
efficacy*,
lm/W CRI *
(Ra) CCT*,
K Weight,
kg
DA-INDIANPOSY1x1800 D342 T830 168 168 172 1715 13,5 127 80+ 3000 1,0
DA-INDIANPOSY1x2400 D343 T830 168 168 172 2330 19,8 118 80+ 3000 1,0
DA-INDIANPOSY1x3200 D344 T830 168 168 172 3137 26,8 117 80+ 3000 1,0
DA-INDIANPOSY1x1800 D342 T840 168 168 172 1813 13,5 134 80+ 4000 1,0
DA-INDIANPOSY1x2400 D343 T840 168 168 172 2463 19,8 124 80+ 4000 1,0
DA-INDIANPOSY1x3200 D344 T840 168 168 172 3316 26,8 124 80+ 4000 1,0
