Description

DA-INDIANPOSY C LED

Downlights Surface mounted LED downlight
direct
opal polycarbonate diffuser
aluminium
white (RAL9016)
MDA- 220 -240V, 50 -60Hz
LED lifetime, 60000/L80B10
3
I
IP44
IK04
Operating temperature range, ta 0+35
On the ceiling. Push -in terminal, 3x2x2.5mm2
Indoor
Office, education, hotel, corridor, bathroom, retail, showroom, exhibition, public place

Product Length,
mm Width,
mm Height,
mm Luminaire
output*, lm System
power*,
W System
efficacy*,
lm/W CRI CCT*,
K Weight,
kg
DA-INDIANPOSY C LED1x1400 D345 T830 OP 200 200 130 1261 11,8 107 80+ 3000 1,0
DA-INDIANPOSY C LED1x1900 D346 T830 OP 200 200 130 1774 16 111 80+ 3000 1,0
DA-INDIANPOSY C LED1x2600 D347 T830 OP 200 200 130 2458 23,1 107 80+ 3000 1,0
DA-INDIANPOSY C LED1x1400 D345 T840 OP 200 200 130 1321 11,8 112 80+ 4000 1,0
DA-INDIANPOSY C LED1x1900 D346 T840 OP 200 200 130 1858 16 116 80+ 4000 1,0
DA-INDIANPOSY C LED1x2600 D347 T840 OP 1G 200 200 130 2575 23,1 112 80+ 4000 1,0
* 10%. Values apply to an ambient temperature of 25 C. icLighting is constantly developing and
improving its products. The right is reserved to change any product specifications without prior notification
*Photos are for illustrational purposes only. The exact appearance of the product may vary depending on the monitor settings, options selected and other factors.

STANDARD
T830 Colour temperature 3000K, CRI 80+
T840 Colour temperature 4000K, CRI 80+
DALI Driver with DALI interface and switch -control dimming
EM3 Emergency version 3 hours
EM3B Emergency version 3 hours (best available technology)
*note – EM3 D347
EM3A Emergency version equipped with an autonomous testing system, 3 hours
EM3D Emergency version 3 hours with DALI interface
SUS Suspended version
RAL RAL colour Suspension MTG KIT SUSI
Suspension wire set “I” type, 1.5m adjustable, 1pcs
*note – 3pcs MTG KIT SUSI for one fitting required
*note – SUS option is required
