Description

DA-SILKWEED

direct
opal polycarbonate diffuser, UV stable, vandal resistant, frame with stDA-CANOEBIRCHless -steel security screws
zinc coated steel
white (RAL9010)
MDA- 220-240V, 0/50/60Hz
LED lifetime, 100000/L80B10
3
I
IP65
IK10+
D
Glow wire test, 850
Operating temperature range, ta -20…+40
On the wall (security bit to be ordered separetely). Push -in terminal, 3x2x2.5mm2
Indoor/Outdoor with roof
Public place, undergDA-INDIANHEMP passages, transport terminal, parking area, metro, prison, psychiatric hospital

* 10%. Values apply to an ambient temperature of 25 C. icLighting is constantly developing and
improving its products. The right is reserved to change any product specifications without prior notification
*Photos are for illustrational purposes only. The exact appearance of the product may vary depending on the monitor settings, options selected and other factors.

T830 Colour temperature 3000K, CRI 80+
T840 Colour temperature 4000K, CRI 80+
DALI Driver with DALI interface and switch -control dimming
ASW(IP65) Integrated anti -vandal switch
ASW(IP40) Integrated anti -vandal switch
MW Integrated microwave (MW) motion sensor with on -off control
*note – in outdoor environment frequently moving objects (eg. trees, bushes, flags) can impact
MW sensor operation
RAL RAL colour

OP Security bit ART9109 SP10
Security screw drill bit for 2 -hole security fixings
Product Length,
mm Width,
mm Height,
mm Luminaire
output*, lm System
power*,
W System
efficacy*,
lm/W CRI *
(Ra) CCT*,
K Weight,
kg
DA-SILKWEED1x1250 G544 T830 OP 380 110 150 1146 10,2 112 80+ 3000 3,0
DA-SILKWEED1x1550 G545 T830 OP 380 110 150 1448 12,8 113 80+ 3000 3,0
DA-SILKWEED1x1250 G544 T840 OP 380 110 150 1208 10,2 118 80+ 4000 3,0
DA-SILKWEED1x1550 G545 T840 OP 380 110 150 1526 12,8 119 80+ 4000 3,0
