Description

DA-WHITEMAPLE LED

direct
tempered glass diffuser
aluminium
dark grey, RAL7043 MDA- 220 -240V, 50 -60Hz
LED lifetime, 50000/L80B50
5
I
IP65
IK08
Operating temperature range, ta -30+45
On the wall. Screw terminal, 3x1x2.5mm2
Outdoor
Facade illumination, parking area, park, public space

* 10%. Values apply to an ambient temperature of 25 C. icLighting is constantly developing and
improving its products. The right is reserved to change any product specifications without prior notification
*Photos are for illustrational purposes only. The exact appearance of the product may vary depending on the monitor settings, options selected and other factors.

T830 Colour temperature 3000K, CRI 80+
T840 Colour temperature 4000K, CRI 80 +

STANDARD
Product Length,
mm Width,
mm Height,
mm Luminaire
output*, lm System
power*,
W System
efficacy*,
lm/W CRI *
(Ra) CCT*,
K Weight,
kg
DA-WHITEMAPLE1x900 J788 T830 111 95 111 840 8,5 99 80+ 3000 0,61
DA-WHITEMAPLE1x900 J788 T840 111 95 111 875 8,5 103 80+ 4000 0,61
